The practical draughtsman's book of industrial design, and machinist's and engineer's drawing companion; forming a complete course of mechanical, engineering, and architectural drawing (1871)
Armengaud, Charles A., 1813-1893, Armengaud, Charles, 1813-1893, [from old catalog] joint author, Amouroux, Jules, [from old catalog] joint author, Johnson, William, 1823-1864. [from old catalog] · Philadelphia, H. C. Baird · leaf 27
atone—whether crescendo or diminuendo—the greater will be thedifference of the result from the true one. From this it follows,that if a rule applies not to aU, it can only apply to one propor-tion ; and also, that if it apply to a certain proportion and not toanother, it can only be correct in that… … Set off B I, A J, and c k, equal to h c; join j K, and bisect it in k,and at k erect a perpendicular, cutting c d, or c d produced, at M;then make g e equal to g m ; j, e, i, m, wiU be the centres of thefour circles required. Through the points, j and i, draw m n, m oE p, E Q, each equal to m c ;…
Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
