Practical electricity .. with questions and answers (1911)
Cleveland armature works, [from old catalog] comp, Lincoln, John C. [from old catalog] · [Cleveland, Ohio, Cleveland armature works] · leaf 173
should be connectedtogether to one pole or terminal of the dynamo. Another advantage of the wave winding as comparedwith the lap winding for small machines is that the numberof turns of wire on the armature is half as great with thewave winding as with the lap winding. When one is calculating the… … Figure 63Lap winding on four pole dynamo 163 This is on account of the fact that there are only twopaths for the armature current. The lap winding shown in Fig. 63 is perfectly analogousto the winding shown in Figs. 60 ana 61. In this machinethere are four paths for the current through the…
Electricity
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
