Practical electricity, with questions and answers (1901)
Cleveland armature works, [from old catalog] comp, Lincoln, John C. [from old catalog] · [Cleveland, Ohio, Cleveland armature works] · leaf 163
be carrying 12l^ amperes into the righthand side of the armature and would be, so to speak, one-quanter commutated. As the commutator bar c leaves thebrush the current flowing from the brush into the commu-taitor bar c will diminish until at the instant the barleaves the brush it will be zero, and… … Figure 57Current from armature 50 amperes. Current into bar e, 25 am-peres and into bar b, 25 amperes. Current through bothc and b, 25 amperes leach. Current in coil b,none. Current in coils a and c, 25 amperes each. the brush would rest equally on the baTs a and b, 25 am-peres would flow into each…
Electricity · Electric generators
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
