. 68.)A magnet holds the handle in opposition to the spring inthat position in which all the resistance is cut out. The TS2 mag-net is usually energized by the current which passesthrough the shunt coils on the motor. If, for any reason,the power which operates the motor should fail, the mag-net… … Figure 68Diagram of automatic starting box showing connoetioas. If the resistance in the starting rheostat were entirelycut out and the power was thrown onto the motor fromten to a hundred times full load current w^ould flow throughthe armature, causing* very bad sparking- and almost cer-tainly…
