as concentric circles with the comi^ass. In Fig. 41 a few other sections appear,■0^ selected from the designs of M. N. Forneyand F. Van Vleck, and which are fortunate arrangements. 75. Figs. 42 and 43 are profiles or outlines of mouldings,such as are of frequent occurrence m architectural work. It…
