single eccentric onthe horizontal lay-shaft shown running below and parallel tothe cylinders. The regulating valves which are controlled bythe action of the governor are perfectly balanced against thepressure in the cylinder which results in a very small resist-ance to the governor action,… … Fig. 27. End View of Mesta Engine. The chrome-vanadium piston rod carries the pistons float-ing free from the cylinder walls reducing the wear on the bore,while the piston rings maintain a gas tight contact with thecylinder walls. Each piston rod is made in two halves, thejoint between the sections…
