ENGINES the side of the cylinder head by means of the autogenous proc-ess. It is also evident that this construction enables the inletvalves to be easily removed, since these screw into the pistonhead. Both inlet and exhaust valves in the Gnome engine areremoved with the greatest ease, special… … Fig. 55. Gnome Motor Running On Test Stand. From Scientific American. pass through the automatic inlet valve in the head of thecylinder. The spark produced by the high tension magneto is ledto the proper cylinder through a brush that presses on arevolving ring of insulating material in which is…
