esign. Fig. 63 of the accompanying drawings is a sectional side ele-vation of the engine, which, it will be seen, is similar in gen-eral disposition to the usual arrangement of the rotating cyl-inder type. In this particular case, however, the short end Aof the stationary crankshaft is reduced in… … r Fig. 64. Farcot Fan Plates. of which mesh with small intermediate pinions carried on aspider F attached to the crankshaft. These pinions are inturn driven by an internally toothed ring G attached to thehub of the crank case H. Thus the blower D is driven in theopposite direction to the crank-case…
