Practical hand book of gas, oil and steam engines, stationary, marine, traction; gas burners, oil burners, etc.; farm, traction, automobile, locomotive; a simple, practical and comprehensive book on the construction, operation and repair of all kinds of engines (1916)
Rathbun, John B. [from old catalog] · Chicago, Charles C. Thompson co · leaf 227
. In this figure, A and C are the two electrodes pro-vided with platinum contact points N and O respectively. The 222 GAS, OIL AND STEAM ENGINES electrode A is stationary and is insulated from the iron casingK by the insulating washer H, and the insulating bush-ing or tube I. The electrode C is… … Fig. 91. Kingston Cylindrical Make and Break Coil. nection with the shell K, and the engine frame at all times,and is provided with a brass bushing F for a bearing surface.The outer containing casing K is bolted to the combustionchamber of the engine by the bolts LL, so that the electrodesA and C…
Internal combustion engines · Traction-engines
