Practical hand book of gas, oil and steam engines, stationary, marine, traction; gas burners, oil burners, etc.; farm, traction, automobile, locomotive; a simple, practical and comprehensive book on the construction, operation and repair of all kinds of engines (1916)
Rathbun, John B. [from old catalog] · Chicago, Charles C. Thompson co · leaf 227
Fig. 91. Kingston Cylindrical Make and Break Coil. nection with the shell K, and the engine frame at all times,and is provided with a brass bushing F for a bearing surface.The outer containing casing K is bolted to the combustionchamber of the engine by the bolts LL, so that the electrodesA and C… … Fig. 92. Kingston Make and Break Coil. Short Type. Current from the battery R passes through the coil windingP to the coil terminal U from which it passes from V to theigniter binding post J. From J it flows along the rod D tothe stationary electrode A. Since the rod D is surrounded bythe…
Internal combustion engines · Traction-engines
