Millikan, Robert Andrews, Gale, Henry Gordon · Boston : Ginn and Co. · leaf 219
oodfrom the ideal diagram shown in Fig. 181. Steam generatedin the boiler B by tlie fire F passes through tlie pipe S into 190 CHANGE OF STATE the steam chest V, and thence through the passage N into thecyhncler C, where its pressure forces the piston F to the left.It will be seen from the figure… … Fig. 181. Ideal diagram of a steam engine iV will have been closed, while the passage M will have beenopened, thus throwing the pressure from the right to the leftside of the piston, and at the same time putting the right end ofthe cylinder, which is full of spent steam, into connection withthe…
Physics
Internet Archive · UBC Library · Public Domain Mark 1.0. Free to use for anything.
