Practical plane and solid geometry for advanced students, including graphic statics, adapted to the requirements of the South Kensington syllabus (1899)

Harrison, Joseph, Baxandall, George Albert · London Macmillan · leaf 244

An illustration from Practical plane and solid geometry for advanced students, including graphic statics, adapted to the requirements of the South Kensington syllabus, 1899, leaf 244
lines are given by their figured plans, Fig. (e). From the point P on one of them draw a line 2-J long, terminating on the other. Unit = 0.05. (1886) Hint.—Proceed as in Ex. 31, obtaining an elevation of AB on the vertical plane whose horizontal trace is ab. *33. Find the length of the line CD in… … CHAPTER X THE OBLIQUE PLANE 197. Introduction.—As defined in Art. 1S3, an obliqueplane is one which is inclined to both planes of projection.The traces are both inclined to xy, or both parallel to it, orboth coincide with it; and the true angle between thetraces is not a right angle. The figure…

Geometry, Descriptive -- Problems, exercises, etc · Geometry, Plane -- Problems, exercises, etc · Graphic methods

Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
