Practical plane and solid geometry for advanced students, including graphic statics, adapted to the requirements of the South Kensington syllabus (1899)

Harrison, Joseph, Baxandall, George Albert · London Macmillan · leaf 258

An illustration from Practical plane and solid geometry for advanced students, including graphic statics, adapted to the requirements of the South Kensington syllabus, 1899, leaf 258
given the plan and elevationof a point A, and one trace of a plane which contains A,to find the other trace. Let a, a, and th be given, Fig. (a). Draw be through a ; project b; through c draw the pro-jector to intersect ba produced in c. Then tc is the re-quired vertical trace. If the given trace… … y (a) {b) h 210 and 211

Geometry, Descriptive -- Problems, exercises, etc · Geometry, Plane -- Problems, exercises, etc · Graphic methods

Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
