Practical plane and solid geometry for advanced students, including graphic statics, adapted to the requirements of the South Kensington syllabus (1899)

Harrison, Joseph, Baxandall, George Albert · London Macmillan · leaf 358

An illustration from Practical plane and solid geometry for advanced students, including graphic statics, adapted to the requirements of the South Kensington syllabus, 1899, leaf 358
oughc and m is therequired vertical trace. Examples.—1. Draw the plan and elevation of a cone with itsbase on the ground, diameter of base if, height 2^. Drawthe traces of a plane which touches the cone along a generatorwhose plan makes 450 with xy. 2. Draw the plan and elevation of a line inclined… … 344 PRACTICAL SOLID GEOMETRY chap. 287. Problem.—A given cone, vertex V, rests with itsbase on the horizontal plane, determine the traces of aplane which shall pass through a given external point Pand be tangential to the cone. The required plane must contain the line VP. Thereforeobtain h, the…

Geometry, Descriptive -- Problems, exercises, etc · Geometry, Plane -- Problems, exercises, etc · Graphic methods

Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
