Practical plane and solid geometry for advanced students, including graphic statics, adapted to the requirements of the South Kensington syllabus (1899)

Harrison, Joseph, Baxandall, George Albert · London Macmillan · leaf 74

An illustration from Practical plane and solid geometry for advanced students, including graphic statics, adapted to the requirements of the South Kensington syllabus, 1899, leaf 74
A\ 2K IB D … N M Examples.—1. Construct a triangle having the vertical angle55°j altitude 2, and perimeter 5 inches. 2. Construct a triangle having the base 2, altitude \\, and perimeter 5 inches. 3. The three medians of a triangle are i|, 2j, and 3 ; draw the triangle. 4. Construct a triangle having its base…

Geometry, Descriptive -- Problems, exercises, etc · Geometry, Plane -- Problems, exercises, etc · Graphic methods

Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
