A practical treatise on weaving and designing of textile fabrics : with chapters on the principles of construction of the loom, calculations and colour (1879)
Ashenhurst, Thos. R. (Thomas R.) · Bradford : T. Brear ; London : Simpkin, Marshal · leaf 72
g, that is, the black dots represent the weft aspassing over the warp thread. To effect this, the threadsrepresented by the white spaces must be raised, and thoserepresented by the black left down for the shuttle to passover. The design is placed before the card-cutter, betweentwo laths, in such a… … Fig. lo. the plate corresponding with the white space upon hispaper, every eighth line upon his paper being thicker thanthe rest, so dividing the squares into eights to correspondwith the number of holes in a row of his plate. The cardand plate are then placed in the stamping machine andthe card…
Textile fabrics · Textile design · Weaving
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
