A practical treatise on the use of the microscope, including the different methods of preparing and examining animal, vegetable, and mineral structures (1848)

Quekett, John, 1815-1861 · London, H. Bailliere · leaf 273

An illustration from A practical treatise on the use of the microscope, including the different methods of preparing and examining animal, vegetable, and mineral structures, 1848, leaf 273 — s when fitted to a body of the improvedcompound microscopes in common use. The same letterswill be used for the corresponding parts in figs. 143 to 148,which represents the various parts of the goniometer fitted upas the eye-piece of a microscope, together with those of theadjusting stage to… … Fig. 143. Fig. 144. double refracting Iceland spar—a Rochons prism of quartzmay be substituted; b is a brass tube containing the prism,with a round aperture forming the cap of the eye-piece, andsliding stiffly on the tube c attached to the arm d carrying thevernier of the graduated circle h. At/is…

Microscopy
