Practice of architecture : containing the five orders of architecture and an additional column and entablature, with all their elements and details explained and illustrated, for the use of carpenters and practical men. (1835)

Benjamin, Asher, 1773-1845 · Boston : Pub. by the author [etc.] ; New York : Collins & co. · leaf 121

An illustration from Practice of architecture : containing the five orders of architecture and an additional column and entablature, with all their elements and details explained and illustrated, for the use of carpenters and practical men., 1835, leaf 121
I/.23^ … i Sf¥V// PEDESTALS. 65 outline of one adapted to this example. The vertical height of thevolute is twenty-eight and one half minutes, and its breadth twenty-four and three fourth minutes. The eye is six minutes in diameter;and the square within the eye, where are to be seen all the centreson which…

Architecture · Architecture -- Orders · Carpentry
