Practice of architecture : containing the five orders of architecture and an additional column and entablature, with all their elements and details explained and illustrated, for the use of carpenters and practical men. (1835)

Benjamin, Asher, 1773-1845 · Boston : Pub. by the author [etc.] ; New York : Collins & co. · leaf 78

An illustration from Practice of architecture : containing the five orders of architecture and an additional column and entablature, with all their elements and details explained and illustrated, for the use of carpenters and practical men., 1835, leaf 78
the triglyph with its details, all ofwhich are accurately figured in minutes. A represents a front, andB a side view of one of the guttse, drawn on a large scale. C showsthe inverted plan of A, and D that of B. The circular line / en-closes the base of A and e, the neck. B is supposed to match… … s®s5rs(S cBiaffi):im.i

Architecture · Architecture -- Orders · Carpentry
