Primitiae gnomonicae catoptricae, hoc est, Horologiographiae nauae specularis ... (1635)
Kircher, Athanasius, 1602-1680 · Auenione : Ex typographia I. Piot ... · leaf 163
L I B R I I I. Hi feu lineas fubfidio inftrumenti Azimuthalis fic in horologio defcribes. pofito inftrumento azimu- thico in centro E. ea ratione , vt linea A B. li- neas meridiana exadte refpondeat. Quo fa£to cir- … cumduc femicirculum NSM. ad denos quofuis ordine aut quindenos gradus in inftrumenti cir- culari limbo defcriptos , ( nos hic promouimus ad fingulos denos gradus femicirculum ) referent enim lineas ex centro per di&os gradus dudhe , communes fedliones horizontis , &c circulorum verticalium. Polito…
Sundials
Internet Archive · Getty Research Institute · Public domain (published before 1931). Free to use for anything.
