The principles underlying radio communication (1922)
United States. National Bureau of Standards, Ould, Richard Sheldon, 1889-, United States. Army. Signal Corps · Washington, Govt. Print. Off. · leaf 469
d voltage, for example, is —10, then the plate voltagewill be 220 volts and the plate current 16 milliamperes, as de- 466 ELECTRON TUBES. termined in Fig. 2<51 by the intersection of the dotted line andthe curve marked Grid voltage=—10. In other words,these values are both consistent with the… … FicyZeZ Qrid Voltage - yolts known, then all the other quantities are determined by the tubecharacteristics. Thus, if the grid voltage at any instant can be found fromthe equation eg=—10+60 sinw/—that is, if a sine wave voltageis impressed upon the grid, between limits of —70 and +50volts—then the…
Telegraph, Wireless · Radio
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
