The principles underlying radio communication (1922)
United States. National Bureau of Standards, Ould, Richard Sheldon, 1889-, United States. Army. Signal Corps · Washington, Govt. Print. Off. · leaf 533
id metallicallyconnected to the plate. The radio-frequency choke coil L2 andthe grid condenser C and grid resistance R In parallel are usedIn adjusting the grid a.c. voltage to produce good operatingcharacteristics; this arrangement produces part of the propernegative voltage on the grid of the… … Fig. 294- Signal Corps. U.S.Afmy Radio Telephone SetBox TyPE SCR.67. Receiver Diagram. cuts down the effective plate voltage which is supplied to themodulator tubes by the generator. The condensers C\, C2 andchoke coils Li% L2 form a filter to eliminate the disturbing effectof the commutator ripple…
Telegraph, Wireless · Radio
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
