Projects for beginning woodwork and mechanical drawing (1912)
Griffith, Ira Samuel, 1874-1924 · Peoria, Ill., The Manual arts press · leaf 28
shed sizes or cuttingsizes. On rough stock, or stock that has not beenmill-planed, if the finished size is ffl thick thecutting size will be 1 thick. (Form, reverse side of a Stock Bill) ESTIMATE OF COST OF MATERIAL 2 A 45 square feet of U inch stock (a 7c square ft. of % inch stock (a 5c 1 inch,… … Fig. 2ished stock sizes will indicate the number ofpieces while the cutting size will indicate the sizeof the single piece from which they are to be cut. Remember that length always means alongthe grain of the wood, and that a piece may bewider than long. Under the word Pieces putthe number of…
Woodwork (Manual training) · Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
