Radford's brick houses and how to build them : a standard collection of new, original, and artistic designs for brick houses, apartments, stores and flats, garages, etc. ; together with complete instruction in the manufacture of brick and its practical uses as a building material selected and compiled by William A. Radford ... Every plan designed and executed by a corps of licensed architects of the highest professional standing, assisted by a staff of expert draftsmen. Over 300 designs and details. (1912)

Radford, William A., 1865- · The Radford Architectural Company, Chicago, Ill. and New York, N.Y. · leaf 40

An illustration from Radford's brick houses and how to build them : a standard collection of new, original, and artistic designs for brick houses, apartments, stores and flats, garages, etc. ; together with complete instruction in the manufacture of brick and its practical uses as a building material selected and compiled by William A. Radford ... Every plan designed and executed by a corps of licensed architects of the highest professional standing, assisted by a staff of expert draftsmen. Over 300 designs and details., 1912, leaf 40
preventcracks through uneven settlement.This practice is known as Hoop-ironbond. A method of bonding a veneer ofbrickwork to a wooden building bymeans of iron wire hooks, is shown inFig. 38. Bonding Brickwork in Angles. Va-rious methods of bonding brick wallsunder different conditions, are shownin… … English C&053 Bond(1) Clipped Bond(2) \ \ GnBDE-N Wall Bond(3) Secrete. Bond ozJizaDEizz(-4) FIG. 35. VARIOUS BONDS IN BRICKWORK.1—Each alternate stretcher course breaks joint with the stretcher course below, dividing face of wall into St.Georges crosses, as shown at 1, 2, 3; 2—Clipped or…

Brick houses -- Designs and plans · Architecture, Domestic -- United States -- Designs and plans · Trade catalogs -- Architecture, Domestic -- Designs and plans
