Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 267
FIG. 171 … FIG. 172 the Cyma Recta shown in Fig. 172, which is theform most generally used, let n and o be the pointsto be united by the moulding. Draw the Hne n o,and bisect it; with half n o as a base describe anequilateral triangle on the opposite sides of theUne; then the apices of the triangle will be…
Architecture · Building
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
