Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 306
The simplest and perhapsthe best method of lengthening a beam is to abutthe ends together, and place a piece on each side; I • ■■ I I) !• •■ || •! Ii t FIQ. 231 these, when firmly bolted together, form a strongand simple connection. Such a method of length-ening a tie is shown by Fig. 231, and is…
Architecture · Building
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
