Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 336
CAL CARPENTEY 297 The method of draw-boring for pins inframing is a very old one—much used in Eng-land—and is well illustrated in Fig. 255, whichshows an elevation and a sectional view througha common mortise-and-tenon joint, with theholes for the pin draw-bored. It will be seenthat instead of the…
Architecture · Building
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
