ght of the cellar will permit, whenceit has a gradual fall or pitch from the heater— HEATING AND VENTILATION 83 approximately one inch in each ten feet oflength. The expansion tank is connected fromthe high point of the main above the heater.The flow branches are taken from the top of themain, the… … full uiew £>ectio/?al l/lew Fig. 57. Eureka Fitting, Used on Main to Improve Circulationin Circuit System of Hot-Water Heating. hot water, owing to the fact that as the latteris lighter it hugs the top of the main. Fig. 56 gives a general idea of the construc-tion of this system and the manner…
