Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 136
Fig. 82. Extra Large GateValve with Yoke or Saddle. \vt/. … Interior^ oflfalve Fig. 81. Effect of Setting a Globe Valve Vertically. 113 HEATING AND VENTILATION ward. Fig. 81, showing the interior of a globevalve with the stem set vertically, illustratesclearly the difficulty arising from lodgment ofthe water of condensation. With the gate valve for either…
Architecture · Building
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
