Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 137
Interior^ oflfalve Fig. 81. Effect of Setting a Globe Valve Vertically. 113 HEATING AND VENTILATION ward. Fig. 81, showing the interior of a globevalve with the stem set vertically, illustratesclearly the difficulty arising from lodgment ofthe water of condensation. With the gate valve for either… … Fig. 83. Steam Radiator Valve. Fig. 84. Hot-Water Eadiator Valve. cured, as will be noticed from the interior view,Fig. 80. Small globe and gate valves are usuallymade of brass; and sizes above 2-inch or 2i/2-inch,ordinarily of iron, in some cases with brass trim-mings. Extra large valves are…
Architecture · Building
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
