Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 215
Fig. 18. Low-Tank Tjrpe of Water-Closet. we are through with this stack until time forsetting the fixtures. It will be seen that when we set these fix-tures, it will be necessary to wipe a joint be- … 182 .ML PLUMBING 183 tween the vent pipe now in, and the vent pipefrom the traps, and this connection will leaveplenty of spring in the piping for expansionand contraction. In some localities the connec-tion between the vents in the wall and the trapvents is made by means of slip joints, with…
Architecture · Building
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
