Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 299
Pig. 75. Waste- and Vent-Piping for Single Fixture. varied to suit requirements. The floor of thetoilet-room is raised about 2i/2 feet above thehall floor, and this permits of the roughing-in,without any great amount of cutting or notchingof timbers, and gives ease of access in case of … RANGE OF SIPH0N-JP:T URINALS WITH HAND FLUSH. PLUMBING 257 necessary repairs or to clear stoppages. Clean-out plugs are placed at convenient points topermit of easy access to the interior of the wasteXDiping. The closet tanks go in the space be-tween the stall partitions, as shown in Fig. 77. Fig.…
