ith sea and check vales, thus providinga positive safeguard against back-pressui^e—amatter to be carefully considered by marineunderwriters, as well as by the owner. Figs. 98 and 99 illustrate a steam yacht fittedwith this system, in which the roughing-in be-low the deck is seen. Owing to the fact… … Fig. 99. Plan of After Portion of Steam Yacht with Ellis Systemof Marine Plumbing. necessary to build a special drainage tank fittedto suit the space as shown. The drains andwastes from the owners bathroom have to passthrough the water storage tank by means of asleeve with reinforced flanges at…
