Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)

Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 59

An illustration from Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work, 1909, leaf 59
^hort nipple Taaon main rig. 17. Branch Connection to Steam Main by Nipple and 90-Degree Elbow, The method shown in Fig. 18 is preferred forthe reason that in all low-pressure mains the -. , . _ f^^ ElbowShort m … \ 3 ^Branch T^0 on main Fig. 18. Branch Connection to Steam Main by Nipple and 45-Degree Elbow. steam flows along the top, the condensationalong the ])ottom. With the 45-degree connec-tion, the condensation from each branch enters HEATING AND VENTILATION 39 the main without saturating the steam,…
