Eiders Fig. 46. Two Eadiators on Same Floor F«d by a Common Riser—Larger Radiator Connected to Top, and Smaller to Side of Riser. taken from the side of the one supplying thesecond-floor surface, as illustrated in Fig. 45.Note the application of the reducing tees on theriser. … Fig. 47. O. S. Distributing Fitting, When two radiators on the same floor arefed by a riser, the larger one should be supplied HEATING AND VENTILATION 75 from the top of the riser, and the smaller radi-ator from the side of the riser, as shown inFig. 46.
