Radford's portfolio of details of building construction : a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale ... (1911)
Radford, William A., 1865-, Johnson, Bernard L, Rawson, Charles P · Chicago : The Radford Architectural Company · leaf 147
5CCTI ON TtfBOUGH COVHEml Pu^rsi CxTEPlOEflNDlNTECion Jection ARRANGEMENT IN FRAME WALL … SECTION P! PLATE 134—CIRCLE HEAD WINDOW FINISHED SQUARE INSIDE Interior and exterior elevations and details ofconstruction of a segmental head window finishedwith a square soffit inside. In this window thesash are of the outward opening casement typeand the transom is stationary. The letters on the…
Building · Architecture
Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
