Radford's portfolio of details of building construction : a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale ... (1911)
Radford, William A., 1865-, Johnson, Bernard L, Rawson, Charles P · Chicago : The Radford Architectural Company · leaf 73
he outside by thesegmental arch (B) of face brick. The inner 8inches are supported by a permanent wood center(C) and the two-row-lock relieving arch (AA). E indicates the furring which should be used toprevent dampness. Fig. 112, section through jambshowing space (G) filled with mortar or…
Building · Architecture
Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
