a brick relieving arch on top of a brick wall, the weight above the window open- timber lintel. Fig. 115, section through window ing, including floor joists, being supported by head, showing angle iron supporting flat brick two steel I-beams. Such I-beams are necessary arch and I-beams supporting… … PLATE 62—DOUBLE HUNG WINDOW IN 18 BRICK WALL Pig 119 section through window head. Fig. ter applied direct to the brick work. When this 120 section through window jamb. Fig. 121, sec- is done the wall should be thoroughly coated with tion through window sill. Note that furring and a waterproofing…
