Radio for everybody; being a popular guide to practical radio-phone reception and transmission and to the dot-and-dash reception and transmission of the radio telegraph, for the layman who wants to apply radio for his pleasure and profit without going into the special theories and the intricacies of the art (1922)

Lescarboura, Austin C. (Austin Celestin), 1891- · New York, Scientific American publishing company [etc.] · leaf 124

An illustration from Radio for everybody; being a popular guide to practical radio-phone reception and transmission and to the dot-and-dash reception and transmission of the radio telegraph, for the layman who wants to apply radio for his pleasure and profit without going into the special theories and the intricacies of the art, 1922, leaf 124
, while the ground is represented RADIO FOR EVERYBODY 105 by a counterpoise made up of all the metal fittings andstay wires and control cables of the machine. The counterpoise is especially efficient and almost neces-sary in conjunction with continuous wave transmission, aswill be described farther… … How the lightning: switch is installed. It should always beinstalled on the outside of the building, with the ground wiregoing as straight as possible. The blade of the switch is con-nected with the antenna, one jaw^ is connected w^ith the receivingset, and the other is connected directly to the…
