Radio for everybody; being a popular guide to practical radio-phone reception and transmission and to the dot-and-dash reception and transmission of the radio telegraph, for the layman who wants to apply radio for his pleasure and profit without going into the special theories and the intricacies of the art (1922)

Lescarboura, Austin C. (Austin Celestin), 1891- · New York, Scientific American publishing company [etc.] · leaf 236

An illustration from Radio for everybody; being a popular guide to practical radio-phone reception and transmission and to the dot-and-dash reception and transmission of the radio telegraph, for the layman who wants to apply radio for his pleasure and profit without going into the special theories and the intricacies of the art, 1922, leaf 236
SG Short woveCondenser Same arrangement as shown on the fac-ing page, but with an aerial inductanoeor loading coil for increasing the w^avelength, and a ground series condenser forreducing the wave length, of the aerial-ground circuit. … 218 RADIO FOR EVERYBODY teur transmission. So the components must be placedclose together, and connected with the shortest possibleconductors. This also applies to the connection with theaerial, which should be made as short and as direct aspossible, in order to secure high efficiency and keep…
