nd the speed50 revolutions per minute; the pistcm velocitybeing thus (00ft. per minute. The high pressurepiston rod is steel, with a diameter of 4|iii , and thelow pressure rod is 6fin. diameter. The crankshaft is 17in. diameter and 34in. long in the necks,the body being 19in. and the wheel l)0ss… … 196 round the pin 21 in. diameter, the thickness of theintervening web being 8in. The crank pins, whichare made of steel, are lOin. diameter in the journalsand 12in. long. The connecting rods are 18ft.long between centres, and are 10Jin. diameter attheir largest part. The air pumps provided…
