Recent cotton mill construction and engineering (1894)
Nasmith, Joseph · London : J. Heywood · leaf 72
Fig. 24. 69 beiDg of gun metal and the valves of india-rubberof special form, as used in the Greenwichengines. The whole of the interior of the pumpmay be quickly examined by removing four nuts.The suction and delivery outlets may be arrangedto suit the position in which the pump is placed.The pump… … Fig. 25. The Grinnell automatic sprinkler, Figs. 25and 26, which is the most extensively used andwidely known, has the peculiar feature of a springdiaphragm, forming the valve seat. Theopening of the Grinnell is half an inch in diameter,and the flexible diaphragm surrounds it. Thevalve was until…
Textile factories -- Design and construction · Cotton manufacture · Cotton machinery
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
