JoFi^. 166 at L\ find point b; with the foot at b, strike the arc c f; withthe foot at d, find point i ; with the foot at a, strike the ii6 GUIDE AND ASSISTANT arc d c; with the foot at c, find point 2 ; then connect a e,c f and / b. 144—To Lay Out a Hexagon Bay Window whenthe Length of One Side is…
