Richey's guide and assistant for carpenters and mechanics : a work of practical information, giving almost every geometrical and practical problem likely to arise in the work of the carpenter, and quick and easy methods for their solution : the use of the steel square, etc., tables showing strength and weight of materials, methods of framing, useful recipes, etc., etc. (1894)

Richey, H. G. (Harry Grant), b. 1868 · New York : W.T. Comstock · leaf 134

An illustration from Richey's guide and assistant for carpenters and mechanics : a work of practical information, giving almost every geometrical and practical problem likely to arise in the work of the carpenter, and quick and easy methods for their solution : the use of the steel square, etc., tables showing strength and weight of materials, methods of framing, useful recipes, etc., etc., 1894, leaf 134
V Fig^ 191 HgJOZ Tig.y.S3 FOR CARPENTERS AND MECHANICS. 127 mast when both ends of the rope are used as guy Hnes;A, blackwall hitch. Fig. 195. 164—Methods of Splicing Timbers.—Fig-. 196. 165—To Find the Contents of a Round Taper-ing Stick of Timber.—Multiply the diameter of one … end by the diameter of the other end, and to this productadd one-third of the square of the difference of the diame-ters ; then multiply this answer by .7854, which gives themean area between the two ends, which multiplied by theheight gives the cubical contents, as: Find the contentsof a round…

Carpentry
