Richey's guide and assistant for carpenters and mechanics : a work of practical information, giving almost every geometrical and practical problem likely to arise in the work of the carpenter, and quick and easy methods for their solution : the use of the steel square, etc., tables showing strength and weight of materials, methods of framing, useful recipes, etc., etc. (1894)

Richey, H. G. (Harry Grant), b. 1868 · New York : W.T. Comstock · leaf 20

An illustration from Richey's guide and assistant for carpenters and mechanics : a work of practical information, giving almost every geometrical and practical problem likely to arise in the work of the carpenter, and quick and easy methods for their solution : the use of the steel square, etc., tables showing strength and weight of materials, methods of framing, useful recipes, etc., etc., 1894, leaf 20
Fig. 4 FJg.S ular and want to find the hypotenuse, which is done inthe following way : Take the square of the base, which is5x5 = 25, and the square of the perpendicular, which is5x5 = 25; add these two answers together, which is 14 GUIDE AND ASSISTANT length 25-,2S = 50, the sum of the squares of…

Carpentry
