Richey's guide and assistant for carpenters and mechanics : a work of practical information, giving almost every geometrical and practical problem likely to arise in the work of the carpenter, and quick and easy methods for their solution : the use of the steel square, etc., tables showing strength and weight of materials, methods of framing, useful recipes, etc., etc. (1894)

Richey, H. G. (Harry Grant), b. 1868 · New York : W.T. Comstock · leaf 84

An illustration from Richey's guide and assistant for carpenters and mechanics : a work of practical information, giving almost every geometrical and practical problem likely to arise in the work of the carpenter, and quick and easy methods for their solution : the use of the steel square, etc., tables showing strength and weight of materials, methods of framing, useful recipes, etc., etc., 1894, leaf 84
h b, and withe and f as centres and e kas radius draw arcs g ^and i k, completing theFis 104- curve of the arch. 98—To Draw the Lancet Gothic Arch when theSpan and Rise are Given.—On the base line, Fig, 105,mark the span a b and from the centre draw the rise c d;now connect a d and d b, and from… … yS GUIDE AND ASSISTANT 99—Gothic Arch.—The most common Gothic arch isone whose radius is equal to its width, as shown in Fig.

Carpentry
