Richey's guide and assistant for carpenters and mechanics : a work of practical information, giving almost every geometrical and practical problem likely to arise in the work of the carpenter, and quick and easy methods for their solution : the use of the steel square, etc., tables showing strength and weight of materials, methods of framing, useful recipes, etc., etc. (1894)

Richey, H. G. (Harry Grant), b. 1868 · New York : W.T. Comstock · leaf 87

An illustration from Richey's guide and assistant for carpenters and mechanics : a work of practical information, giving almost every geometrical and practical problem likely to arise in the work of the carpenter, and quick and easy methods for their solution : the use of the steel square, etc., tables showing strength and weight of materials, methods of framing, useful recipes, etc., etc., 1894, leaf 87
rjg.ioa 104—To Draw the Soffit or Veneering of a Drop orGothic Arch with Splayed Jambs.—Draw a section ofthe arch, showing theposition of the jambs,Fig. 113. From one ofthe centres, as c, draw aperpendicular line in-definite, as c d; con-tinue the face line ofjamb a to bisect c d 2Xd; then d is the… … ier enf re. centre^ing the slope of the veneering at the top of arch.

Carpentry
