m €^ D=ie Fig. 87.—Magnetic Detector—Marconi. 142 MANUAL OF RADIO TELEGRAPHY AND TELEPHONY. Fig. 92 represents circuits of a receiving set complying with presentspecifications. In all such sets closed circuits are calibrated and curvesdrawn or a scale furnished showing wave lengths for all settings… … Fia. 88.—Audion. to 4000 meters, and additional calibrated loading coils for very long wavesare supplied. With very loose coupling the wave length of received signals can thus beread directly. 200. Fig. 89 represents receiving circuits for continuous oscillations;it shows the receiving telephone…
