Rogers' drawing and design; an educational treatise relating to linear drawing; machine design; working drawings; transmission methods; steam, electrical and metal working machines and parts; lathes; boiler and parts; instruments and their use; tables, etc (1913)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 163
the same manner the distances NJ and J2,Fig. 294, are laid off on the lines gfpand gfp; thedistances OK and Ki, Fig. 294, are laid off on thelines deo and deo and the distances PL and LP,Fig. 294, are laid off in the same way, on the linescbn and cbn. and m by two other arcs, drawn from the points… … Fig. 294. Now trace a curve through the points c, d, g, h,k, h, g, d and c and another curve through thepoints, n, o, p, q, 1, q, p o and n. From the points n and n as centers, describe arcswith a radius nm equal to nm each equal to EF, inFig. 294 and intersect these arcs in the points m The dotted…
Mechanical drawing · Machine design
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
