Rogers' drawing and design; an educational treatise relating to linear drawing; machine design; working drawings; transmission methods; steam, electrical and metal working machines and parts; lathes; boiler and parts; instruments and their use; tables, etc (1913)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 202
4 .If T y 4 1 … Fig. 328. moment in the preceding example, we see that abeam may carry a load two times greater when theload is distributed uniformly throughout the beam. loaded at the center, as in Fig. 329, the greatestbending moment is at the center and at each end,and is equal to i/^ W x L- This is based on…
Mechanical drawing · Machine design
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
